- Multiple audio inputs and outputs: Support Bluetooth/Balanced XLR/RCA input, compatible with most audio sources such as mobile phones, tablets, TV, CD players, etc. With balanced XLR/RCA/3.5mm headphone jack output, you can connect amplifiers/active speakers/headphones, maintain high-quality lossless audio transmission, and enjoy HiFi sound quality.
- Noiseless JAN5725W tubes: Equipped with two 5725 vacuum tubes, filter digital sense of sound, effectively improve sound quality, output soft and sweet sound; pluggable tube socket design, can be replaced by 6J1, 6K4, 5654, 6AK5, EF95, 403B, etc to enjoy tube sound of different styles.
- Powerful OLED screen display: Intuitively displays Bluetooth connection status/ device volume / EQ sound effects, etc., to let you know the working status at any time; besides, a variety of EQ sound effects are available, which is highly playable and adds a lot of fun.
- High-performance chip: Using QCC5125 Bluetooth module, supporting LDAC 96kHz/24Bit, high transmission and low latency; using CS4344 decoding chip, richer audio details, and wider dynamic range, ensuring better performance.
- Perfect design of appearance and function: Silver-gray body with orange tubes, the overall appearance is exquisite, and the size is just right to decorate your desktop. Modern OLED display screen and a full-featured remote control, convenient and easy to use, suitable for audiophiles.
3.5mm headphone jack output is prior, which means stereo RCA and XLR output will auto disconnect when headphone is inserted.
Parameters
Chips: QCC5125 (Bluetooth chip) CS4344 (DAC chip)
Tubes: 2*JAN5725W
Audio Input: Bluetooth / Balanced XLR / Stereo RCA
Audio Output: Balanced XLR/Stereo RCA / 3.5mm headphone jack
Bluetooth version: 5.0 (support LDAC 96khz/24Bit)
RCA maximum output amplitude: 2V
BAL maximum output amplitude: 4V
Headphone output power: 120mW (32)
Headphone impedance range: 16-300
Distortion: 0.05%
SNR: 103dB
Working voltage: DC 12V
Input Sensitivity: 1Vrms
Frequency response: 20Hz-20KHz (1dB)
Dimensions (W*D*H): 126*167*42mm / 4.96*6.57*1.65in
Package dimensions (W*D*H): 310*240*70mm / 12.20*9.45*2.76in
Net weight: 665g / 1.47lb
Package weight: 1.0kg / 2.20lb
Packing list
1*H8 Preamp
2*JAN5725W Tube
1*DC 12V Power Adapter
1*Bluetooth Antenna
1*Remote Control
