- Improved circuit; Vacuum Tube: Shuguang 12AX7 (ECC83) * 2 / 12AU7 (ECC82) * 2 / 6Z4 * 2. Note: Tube models may vary according to supply chain. Their performance are the same.
- Excellent scaffolding design, reasonable, regular, symmetrical device layout, strictly respect the grounding line
- Power Transformers 76 * 40 H250 0.35 sheets; Japan ALPS 16 A-type audio potentiometer
- Full aluminum chassis with wood side panel; 4 Set of stereo L/R RCA auido input, 1 set of RCA output
Technical Parameters:
Input sensitivity: 400mv
Voltage output: 2V (RMS THD <0.03%)
S / N Ratio: 94DB
Frequency Response: 12Hz-50KHz (-0.5DB)
Input Impedance: 200Kohm
Output Impedance: 600ohm
AC Input: 100V (115V)
Power Consumption: 30W
Dimension (W-D-H): 320 * 170 * 120 mm / 12.6 * 6.69 * 4.72 in (Add tube height)
Net Weight: 3.5 kg / 7.72 lb, with a packaging weight 4 kg / 8.82 lb
Package Includes:
1 tube preamp
1 Power cord
