- Support MQA & MQA-CD USB, optical, and coaxial support MQA decoding, and support MQA-CD
- Explore the Full Potential of the Chip AK4499EX AK4191 The distortion is as low as 0.00006%(-124dB)
- Brand-new 3rd Generation XMOS XU-316 A true 32-bit USB scheme supports DOP and native DSD, with PCM up to 768kHz and DSD up to DSD512.
- Bluetooth 5.1 Support LDAC, APTX/HD, SBC, AAC!
- Brand-new Design Dual UI design, switch freely Easy-use with friendly operating system Stereoscopic relief panel design, fashionable and generous
SPEC:
InputUSB/optical 1/optical 2/coaxial 1/coaxial 2/1IS/Bluetooth
OutputXLR/RCA
Output Amplitude
XLR 5Vrms
RCA 2.5Vrms
THD N0.00006%(-124dB)(UN-WTD)
Dynamic range
XLR 132dB
RCA 127dB
SNR
XLR 132dB
RCA 127dB
USB transmissionUSB2.0(Asynchronization)
USB compatibilityWindows7 /8/8.1/ 10/ 11(Needs Driver)
Ma c OSX10.6 or aboveLinux(Driverless)
MQA decoderUSB/ Optical / Coaxial
Sampling rate& Bit Width:
USB
PCM 44.1~768kHz(32bit)
DSD2.8224~22.5792MHz(1bit)
DoP2.8224~11.2896MHz(1bit)
Optical/coaxial
PCM44.1~192kHz(24bit)
DoP2.8224MHz(1bit)
Bluetooth specification:5.1(supports SBC,AAC,aptX,aptX HD,LDAC)
Power Consumption<10W
Standby power<0.5W
Size :219x180x45mm (WxHxD)
Weight:1.33kg/2.93lbs
- Package Dimensions : 13.07 x 9.17 x 3.43 inches; 3.73 Pounds
- Date First Available : September 29, 2024
- Manufacturer : LEAUDIO
